TWINSPOT MINI
LED EMERGENCY EXIT LUMINAIRE
The versatile Mini range offers Corridor (narrow beam) and the Open Area (wide beam) emergency lighting projector options. Simple and effective emergency lighting from attractive high intensity LED projectors.
The heads are easily adjusted and make the units suitable for ceiling or wall mounting. The self-contained circuit provides charge healthy monitoring for the 2 x 3.6V 1.5Ah Nickel Metal Hydride (NiMH) batteries.
KEY FEATURES AND SPECIFICATIONS
‣ Polycarbonate body
‣ 3 hour maintained emergency
‣ Lifetime of up to 50,000 Hours
‣ Luminaire lumens 2 x110lm
‣ Dimensions: 186mm (W) x 108mm (H) x 55mm (D)
‣ Cable Entry: 20mm knock-outs top and back
‣ Available as Corridor (narrow beam) or Open Area (wide beam)
‣ Light source 2 x 2Watt LED
‣ Colour temperature 5000K
‣ Ambient temperature (Ta) 25°C
‣ Insulation Class Class II
‣ Supply 230Volt ~ 50Hz
‣ Supply power 5.0 Watts (max.)
‣ Charge power (typical) 1.0 Watts
‣ Battery 2 x 3.6V 1.5Ah NiMH
‣ Weight 2.0kg (max.)
‣ IP20 Rated
NOTES:
NON-MAINTAINED EMERGENCY LUMINAIRES only operate during power failures.
MAINTAINED EMERGENCY LUMINAIRES operate when the power is on, as well as during power failures. The same light source is used in both cases.
Please download the data sheet for further information
APPLICATION
Suitable for a variety of emergency lighting applications in industrial environments.
